Black Box - docking station - USB-C - HDMI, DP - GigE
-
NG # 2351-HW-BLACK-025
-
MF # USBC2000-R2
Manufactured by:
Specification
General USB Charging (2) Type-C female ports support both data (5 Gbps) and PD Charging 100W (20 V / 5 A), plug and play; Supports Fast Role Swap of PD 3.0, the connected device will not get disconnected when plugging in and out PD Adapter. Storage Humidity Operating: 0 to 95%, non-condensing Connector Speed (3) USB 3.0 type A ports support super speed (5 Gbps) transmission, backwards-compatible with USB 2.0. One of the three USB-A ports supports BC 1.2, the power of this port can be up to 7.5W (5V/1.5A);
Supports Secure Digital v3.0 UHS-I (Ultra High Speed): SDR12 (12.5 Mbyte/s)/SDR25 (25 Mbyte/s)/SDR50 (50 Mbyte/s)/DDR50 (50 Mbyte/s)/ SDR104 (104 Mbyte/s) Allows SD and Micro SD card to work at the same timeOperating Humidity 10 to 85% RH (no condensation) Operating Temperature 32 to 113° F (0 to 45° C) Storage Temperature +14 to +158° F (-10 to +70° C) Approvals FCC, CE Power USB-C Female Port, Up to 100 W (20 V/5 A) Item Specifications Connectors Input:
(1) USB-C Female (with Type-C M to M cable);
Output:
(3) USB 3.0 Female;
(1) USB-C Female (for data & charging);
(1) RJ45;
(1) HDMI Female;
(1) Micro SDX;
(1) SD/MMCXCountry of Origin China Dimensions 0.05-in. H x 5-in. W x 2.4-in. D (14.2 x 60.96 x 127-mm) Replaces USBC2000
Description
Portable, mini USB-C docking station Portable Mini USB-C Docking Station Connect a 4K HDMI monitor keyboard and mouse to your MacBook(r) Pro or Windows(r) laptop with this multi-port adapter. The dock includes a USB C host port and cable a USB C charging port an HDMI HD video port a LAN port three high-speed USB 3.0 Type-A ports and an SD/USD memory card reader. Super-Fast and Backward-Compatible The USB C docking station supports USB 3.0 super-speed (5 Gbps) transmission. Even better it's backward-compatible with USB 2.0 so you aren't limited by legacy hardware. Supports USB Power Delivery Power both the multiport adapter and your laptop using your laptop's USB-C power adapter (supports USB Power Delivery 3.0 up to 100 W 85 W of which will power the connected host device). Works on a Range of Platforms This docking station can work on all PCs and mobile phones that support DP 1.4 Alt Mode.
