Eaton 5PX EBM 48V RT2U G2 - battery enclosure
-
NG # 2500-HW-Eaton-007
-
MF # 5PXEBM48RTG2
Manufactured by:
Specification
General
Device Type: Battery Enclosure – Rack-mountable / External
Form Factor: 2U Rackmount
Battery
Battery Quantity: 8
Battery Technology: Lead Acid (Maintenance-free, Sealed, Valve-regulated)
Voltage Provided: 48V
Battery Capacity: 9Ah
Features
Maintenance-free operation
Sealed design ensures safety and leak prevention
Valve-regulated for consistent performance
Dimensions & Weight
Width: 17.2 in (437 mm)
Depth: 17.6 in (447 mm)
Height: 3.4 in (86 mm)
Weight: 61.29 lbs (27.8 kg)
Mounting & Accessories
Rack Mounting Kit: Included
Compatibility
Designed for:
5PX1000RTG2
5PX1000RTNG2
5PX1500HRTG2
5PX1500RTG2
5PX1500RTNG2
EBMCBL48RT
Description
Backup Battery Module Gives Your Compatible Eaton UPS System Extended Runtime
The 5PXEBM48RTG2 offers extended battery runtime when used in conjunction with Eaton's 5PX1000RTG2, 5PX1000RTNG2, 5PX1500RTG2, 5PX1500RTNG2 and 5PX1500HRTG2 5PX G2 UPS systems. It can also be daisy-chained for a maximum of four matching battery packs to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.
Supports 2U Rack or Tower Installation
This backup battery pack's multi-use form factor supports mounting in 2U of space in EIA-standard 19-inch open frame racks or enclosures using the included 4-post rail kit and mounting brackets. Tower stands are also included for optional upright configuration.
