Eaton 5PX EBM 72V RT2U G2 - battery enclosure
-
NG # 2499-HW-Eaton-006
-
MF # 5PXEBM72RTG2
Manufactured by:
Specification
General Information
Device Type: Battery Enclosure (Rack-Mountable / External)
Rack Height: 2U
Battery
Battery Quantity: 12
Battery Type: Sealed Lead Acid (VRLA)
Voltage Provided: 72V
Battery Capacity: 9 Ah
Features: Maintenance-Free, Sealed, Valve-Regulated
Physical Characteristics
Width: 17.2 inches (437 mm)
Depth: 23.7 inches (602 mm)
Height: 3.4 inches (86 mm)
Weight: 89.07 lbs (40.4 kg)
Mounting Kit: Rack Mounting Kit Included
Compatibility
Compatible Models:
Eaton 5PX2000RTG2
Eaton 5PX2000RTNG2
Eaton 5PX2200HRTG2
Eaton 5PX3000HRTG2
Eaton 5PX3000HRTNG2
Eaton 5PX3000RTG2
Eaton 5PX3000RTNG2
EBMCBL72
Description
Backup Battery Module Gives Your Compatible Eaton UPS System Extended Runtime
The 5PXEBM72RTG2 offers extended battery runtime when used in conjunction with Eaton's 5PX2000RTG2, 5PX2000RTNG2, 5PX2200HRTG2, 5PX3000RTG2, 5PX3000RTNG2, 5PX3000HRTG2 and 5PX3000HRTNG2 5PX G2 UPS systems. It can also be daisy-chained for a maximum of four matching battery packs to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.
Supports 2U Rack or Tower Installation
This backup battery pack's multi-use form factor supports mounting in 2U of space in EIA-standard 19-inch open frame racks or enclosures using the included 4-post rail kit and mounting brackets. Tower stands are also included for optional upright configuration.
