General Information

Device Type: UPS (Uninterruptible Power Supply) – External

Color: Black

Power Device

UPS Technology: Line Interactive

Input Voltage: AC 120V

Input Voltage Range: AC 93 – 138V

Frequency Required: 46 – 70 Hz

Input Connector: 1 × NEMA 5-15 (Power)

Output Connectors: 10 × NEMA 5-15 (Power)

Output Voltage: AC 120V

Power Capacity: 900 Watts / 1500 VA

Surge Suppression: Yes

Circuit Protection: Circuit Breaker

Dataline Surge Protection:

RJ-45 (Network/Phone line): 1 Input / 1 Output

F-Type Connector (Cable TV/Satellite/Antenna)

Battery

Battery Quantity: 1

Battery Type: Lead Acid

Networking & Management

Remote Management Interface: USB

Included Software: Eaton UPS Companion (Free Download)

Supported OS: Microsoft Windows, Apple macOS, Linux

Expansion & Connectivity

Interfaces: 1 × USB (Management)

Cables Included:

USB Cable – 6 ft

Integrated Power Cable – 6 ft

Features

Audible Alarm

LCD Display

Automatic Voltage Regulation (AVR)

EcoControl Master/Control Outlets

Compliance & Certification

FCC Class B Certified

UL 1778

FCC Part 15

Warranty

UPS Unit: 3-Year Limited Warranty

Battery: 3-Year Limited Warranty

Environmental Conditions

Operating Temperature Range: 32°F – 95°F (0°C – 35°C)

Humidity (Operating): 0 – 95% (Non-condensing)

Physical Dimensions

Unit Dimensions (W × D × H): 3.4 in × 15 in × 9.8 in

Unit Weight: 25.57 lbs

Shipping Information

Shipping Dimensions (W × D × H): 6.5 in × 19.5 in × 13 in

Shipping Weight: 26.9 lbs
