Eaton standby UPS - 550VA - 300W - 10 NEMA 5-15R outlets - 120V
2530-HW-Eaton-036
Overview
The standby ECO550UPS UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The 10-outlet 120V battery backup is ideal protection for your home office, media center or professional kiosk, security and small-business phone applications, including computers, routers, printers, HDTVs, Blu-ray players, game consoles, ATMs, security systems and digital signage equipment.
| General | |
| Device Type | UPS - external |
| Battery Enclosure Type | Internal |
| Power Device | |
| Load Rating | Individual PC |
| UPS Technology | Off-line |
| Input Voltage | AC 120 V |
| Frequency Provided | 60 Hz |
| Input Voltage Margin | ± 5% |
| Frequency Required | 60 Hz |
| Input Connectors | 1 x power NEMA 5-15 |
| Power Output Connectors Details | 4 x power NEMA 5-15 (UPS and surge) ¦ 4 x power NEMA 5-15 (surge) |
| Output Voltage | AC 120 V 60 Hz |
| Power Capacity | 300 Watt / 550 VA |
| Dataline Surge Protection | Phone line - RJ-11 |
| Surge Suppression | Yes |
| Surge Energy Rating | 420 Joules |
| Battery | |
| Run Time (Up To) | 3.5 min at full load |
| Recharge Time | 15 hours |
| Networking | |
| Remote Management Interface | USB |
| Miscellaneous | |
| Cables Included | Power cable - integrated - 6 ft ¦ USB cable - external |
| Equipment Protection Value | 100000 US Dollars |
| Features | Audible alarm, LED indicators |
| Compliant Standards | CSA, NOM, UL 1778, FCC Part 68, RoHS |
| Software / System Requirements | |
| Software Included | TrippLite PowerAlert (free download) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% |
| Dimensions & Weight | |
| Width | 5.7 in |
| Depth | 10.9 in |
| Height | 3.1 in |
| Weight | 6.61 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 13 in |
| Shipping Depth | 8 in |
| Shipping Height | 4.1 in |
| Shipping Weight | 7.05 lbs |
Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but the ECO550UPS should keep an energy-efficient desktop computer with small LCD monitor powered as long as 16 minutes. During normal operation, incoming utility power keeps the replaceable internal battery fully charged, so backup power will always be available.
