Eaton Tripp Lite Series 72V Extended Battery Module (EBM) for Select 2200VA and 3000VA SmartPro UPS Systems, 2U Rack/Tower, TAA - UPS battery - VRLA - TAA Compliant
TF:
2517-HW-Eaton-024
Overview
Backup Battery Module Gives Your Compatible UPS System Extended Runtime
| General | |
| Device Type | UPS battery - external |
| Height (Rack Units) | 2U |
| Rack Size | 19" |
| Battery | |
| Technology | Valve regulated lead-acid (VRLA) |
| Voltage Provided | DC 72 V |
| Miscellaneous | |
| Included Accessories | Tower stand, 4-post rail kit |
| Cables Included | Battery cable - external ¦ Auto-detection cable |
| Rack Mounting Kit | Included |
| Features | Daisy chaining support, power fail protection, single-phase |
| Compliant Standards | CAN/CSA C22.2, cTUVus, RoHS, UKCA, WEEE |
| TAA Compliant | Yes |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 23.7 in |
| Height | 3.4 in |
| Weight | 89.11 lbs |
| Compatibility Information | |
| Designed For | P/N: SMART2200RXLTAA, SMART3000RXLTAA |
The BP72VRXLTAA offers extended battery runtime when used in conjunction with certain Eaton Tripp Lite series 2200VA and 3000VA SmartPro UPS systems, such as the SMART2200RXLTAA and SMART3000RXLTAA. It can also be daisy-chained for a maximum of four matching battery packs to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.
