Eaton Tripp Lite Series - UPS - 475 Watt - 750 VA - VRLA
2524-HW-Eaton-030
Overview
The SMART750PSRTNC line-interactive cloud-connected UPS system combines cloud connectivity, remote management and advanced protection features. Its slim tower design is suitable for desktop or floor placement or installed in a rack (with optional mounting kit, sold separately). It's recommended for home, office and retail use, as well as network closets in both local and remote locations.
| General | |
| Device Type | UPS - external |
| Height (Rack Units) | 2U |
| Power Device | |
| UPS Technology | UPS Technology |
| Input Voltage | AC 120 V |
| Frequency Provided | 50/60 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 8 x power NEMA 5-15R (UPS and surge) |
| Output Voltage | AC 120 V ± 10% - 50/60 Hz |
| Power Capacity | 475 Watt / 750 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 158 Joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 95% at 100% Load |
| Battery | |
| Technology | Valve regulated lead-acid (VRLA) lead acid |
| Run Time (Up To) | 2 min at full load ¦ 8 min at half load |
| Recharge Time | 8 hours |
| Transfer Time | 6 ms |
| Features | Valve-regulated |
| Networking | |
| Remote Management Interface | USB, NFC, Ethernet |
| Expansion / Connectivity | |
| Interfaces | 1 x USB - 4 pin USB Type A ¦ 1 x USB - 24 pin USB-C |
| Miscellaneous | |
| Cables Included | Power cable - integrated - 5 ft |
| Equipment Protection Value | 250000 US Dollars |
| Features | Audible alarm, diagnostic LED, rack-mountable, tower mountable, remote monitoring, LED status indicators, pure sinewave output, LCD display, Automatic Voltage Regulation (AVR), cold-start function, audible alarm, cooling fan, overvoltage correction, undervoltage correction, VRLA battery support, battery backup capability |
| Compliant Standards | FCC Part 15 B Class B., RoHS, CSA, Mexico NOM, UL 1778 |
| Sustainability Information | |
| ENERGY STAR | Yes |
| Manufacturer Warranty | |
| Service & Support | United States and Canada: limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% RH (non-condensing) |
| Sound Emission | 40 dB |
| Dimensions & Weight | |
| Width | 3.4 in |
| Depth | 12.4 in |
| Height | 13 in |
| Weight | 15.41 lbs |
Easy-to-Use Cloud-Enabled Remote Monitoring Powered by Brightlayer
Eaton's cloud-based remote monitoring app offers convenient setup, control and management of a single UPS or a larger deployment. Scan the QR code on the UPS to download the app to your mobile device. Receive alerts, push configurations, silence alarms or control load banks using a mobile app or web browser. Being able to monitor and access multiple UPS systems from a remote location helps reduce the number of site visits, saving you time and money. The unit's NFC (near-field communication) feature lets you configure network settings instantly from your mobile device.
