Ecom Pad-Ex® 01 P12 DZ2 - Windows® 11 Tablet for Zone 2/22 & DIV 2
-
NG # 001618-HW-ECOM-018
Manufactured by:
While being given its level of ruggedness, the Pad-Ex® 01 P12 offers the latest Intel® 12th Generation processors with Intel® Iris® Xe graphics, delivering outstanding performance and visuals via its neat, compact form. Plus, the high-speed data transmission capability of Thunderbolt™ 4, Intel® Wi-Fi 6E and Bluetooth® V5.3 provides smooth, congestion-free processing at all times.
Specification
Hardware Indicators/operating means Electrical specifications Interface Communication Software Ambient conditions Mechanical specifications General information Processor Intel® Core i5-1235U, 12. Gen.
Optional:
Intel® Core i7-1255U, 12th Gen.RAM 16 GByte DDR5 Camera Optional: Front camera 2 MP Main camera 8 MP Autofocus Scanner Optional:
1-D/2-D barcode scanner
Honeywell N670X Series scan engineInternal data memory 256 GByte NVMe PCIe SSD Sensors Acceleration sensor, gyroscope and e-compass, light sensor Display Can be operated while wearing gloves Touchscreen technology Capacitive multitouch Type TFT, LCD Screen diagonal 29.5 cm (11.6 ") Aspect ratio 16:9 Resolution 1920x1080 (Full HD) Brightness 1000 cd/m2 (nit) Colors 16 Mio. Key On/off
Volume up / down
Windows Touch button
Barcode / Camera Touch Button
Programmable Touch ButtonBattery type Li-Ion battery 43.29 WH 11.1 V 3900 mAh I/O ports 1x Thunderbolt® 4
1x USB 3.2 Gen 2 (Type A)
1x Micro-HDMI
1x Audio in/out (combo jack)
1x microSD card (microSDXC)
1x Docking connector (35-pin Pogo)
1x DC-In jackMobile standard Optional: LTE Module Sierra Wireless EM 7565 Module 3G HSPA+
B1, B2, B4, B5, B6, B8, B9, B19 4G LTE
Please note (only U.S. market): AT&T is the only supported mobile carrier for the U.S. market.
B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B18, B19, B20, B26, B28, B29, B30, B32, B41, B42, B43, B46, B48, B66WLAN Intel® Wi-Fi 6E AX211 (802.11a/b/g/n/ac/ax) Bluetooth Bluetooth® 5.3 GPS sensor GPS, Glonass, Beidou, Galileo SIM card Optional:
1x Nano SIMOperating system Windows® 11 Pro (64 Bit)
TPM 2.0Languages Deutsch , English (default) Ambient temperature -10 ... 55 °C (14 ... 131 °F) Storage temperature -10 ... 55 °C (14 ... 131 °F) Degree of protection IP64
MIL-STD-810H / MIL-STD-461FMass 1200 g Dimensions W x H x D 298 mm x 192 mm x 20 mm Scope of delivery Pad-Ex®
Power supply
Power cable
Dock Connector with Pass-Through
Hand strap
Documentation
Stylus pen with tether
Description
Combining robust features and a large screen size, superior performance is ideal for field operatives of all sectors to complement or even substitute Desktop PC, laptop or wall mounted display.
