ECOM Visor-Ex® 01: Industrial Grade Smart Glasses Wearables for Hazardous Areas
1039-HW-ECOM-004
Overview
With Visor-Ex® 01, service technicians enter a totally new world of on-site work and training. They can connect anytime to expert support and have immediate access to all relevant information.
| CAMERA | 2x central 16 MP camera and 4:3 aspect ratio with flashlight LED, notification LED, 6x optical zoom with liquid lens for fast autofocus and built-in laser (Class 1) |
| SCANNER | Basic: QR, EAN-13, Advanced: 2D, Aztec, multiple barcodes |
| SENSORS | 9-axis sensor (accelerometer, gyroscope, compass) |
| SPEAKER | 85 dB loudspeaker for noisy environments |
| MICROPHONE | Microphone array for voice commands and echo cancellation, Multilingual voice commands |
| DISPLAY | 640 x 400 active color matrix OLED display, Touchpad |
| CONTRAST | 1:10000 |
| BRIGHTNESS | Up to 2000 nits |
| BATTERY TYPE | Li-Ion with 3.7 V / 4400 mAh / 16.28 Wh (built-in) |
| AMBIENT TEMPERATURE | -20 ... +50 °C (-4 ... +122 °F) |
| DEGREE OF PROTECTION | IP54 |
| CONNECTION | 3.5 mm jack connection (for optional headphones and microphone), Coax connection, Magnetic USB connection |
| WEIGHT | Head Unit: approx. 180 g, Pocket Unit: approx. 300 g |
| DIMENSIONS | Head Unit: 212 mm x 53 mm x 53 mm, Pocket Unit: 82 mm x 148 mm x 20 mm |
With Visor-Ex® 01, service technicians enter a totally new world of on-site work and training. They can connect anytime to expert support and have immediate access to all relevant information. Both hands remain free for the work that needs to be done, while digital documents are displayed for reference and consultation.
At the same time, the technician is never left on his own and able to contact experts for audiovisual interaction anywhere and anytime. All this is accomplished by these ergonomically designed smart glasses based on well-established technologies.
