General

Printer Type

Label printer - ink-jet - color

Printer

Inkjet Technology

Epson PrecisionCore TFP

Ink Palette Supported (Colors)

4-ink - cyan, magenta, yellow, matte black

Ink Cartridge Configuration

4 cartridges (1 each: pigment cyan, pigment magenta, pigment yellow, pigment black)

Ink Type

Epson UltraChrome DL

Print Speed

Up to 236.2 inch/min - 300x600 dpi

Built-in Devices

2.7 inch LCD display

Connectivity Technology

Wired

Interface

USB, USB host

Max Resolution (B&W)

1200 x 1200 dpi

Max Resolution (Color)

1200 x 1200 dpi

Max Resolution Class (B&W)

1200 x 1200 dpi

Max Resolution Class (Color)

1200 x 1200 dpi

Language Simulation

ZPL II

Auto Cutter

Yes

Media Handling

Media Type

Labels, fanfold paper, continuous labels, die cut labels, black mark labels

Max Media Size

Roll (4.4 in)

Media Sizes

Roll (1 in - 4.4 in)

Max Printing Width

4.25 in

Media Thickness Range

0.08 mm - 0.23 mm

Roll Maximum Outer Diameter

4 in

Roll Core Diameter

1.73 in

Media Feeders

1 x manual - 1 roll - Roll (4 in)

Expansion / Connectivity

Connections

1 x USB - 4 pin USB Type B ¦ 1 x USB host - 4 pin USB Type A

Miscellaneous

Included Accessories

Paper tray, maintenance kit

Consumables Included

1 x ink cartridge (matte black) - Epson SJIC41P-MK ¦ 1 x ink cartridge (cyan) - Epson SJIC41P-C ¦ 1 x ink cartridge (magenta) - Epson SJIC41P-M ¦ 1 x ink cartridge (yellow) - Epson SJIC41P-Y

Media Included

1 label roll

Compliant Standards

TUV, UL 1950, CSA 22.2 No. 950, ICES-003 Class A, RoHS, GOST-R, VCCI Class A

Power

Voltage Required

AC 100-240 V

Frequency Required

50/60 Hz

Power Consumption Operational

28.2 Watt

Power Consumption Stand by

2.6 Watt

Software / System Requirements

OS Required

Windows 8.1, Microsoft Windows Server 2012 R2 x64 Edition, Windows 10, Microsoft Windows Server 2016 (64-bit), Apple MacOS X 10.9.5 or later, Microsoft Windows Server 2019 (64-bit), Microsoft Windows Server 2012 (64-bit) or later, Windows 11, Apple macOS 11.x

Manufacturer Warranty

Service & Support

Limited warranty - 1 year - depot

Environmental Parameters

Min Operating Temperature

41 °F

Max Operating Temperature

95 °F

Humidity Range Operating

20 - 80% RH

Sound Emission (Operating)

58 dBA

Dimensions & Weight

Width

12.2 in

Depth

11.1 in

Height

11.2 in

Weight

28.66 lbs

Dimensions & Weight (Shipping)

Width (Shipping)

15.6 in

Depth (Shipping)

17.6 in

Height (Shipping)

18.5 in

Weight (Shipping)

38.58 lbs
