General

Type

Document scanner - desktop

Interface Type

USB 3.0

Max Supported Document Size

8.5 in x 240 in

Scanner

Input Type

Color

Grayscale Depth

30-bit color

Grayscale Depth (External)

24-bit (16.7 million colors)

Optical Resolution

600 dpi x 600 dpi

Interpolated Resolution

1200 dpi x 1200 dpi

Scan Mode

Single-pass

Automatic Duplexing

Yes

Scanning Sensor Type

Contact Image Sensor (CIS)

Lamp / Light Source Type

3-color RGB LED

Max Document Scan Speed B/W

45 ppm

Max Document Scan Speed Color

45 ppm

Duty Cycle

7000 scans per day

Scanner Speed Details

45 ppm - black&white - 300 dpi ¦ 45 ppm - color - 300 dpi ¦ 90 ipm - duplex

Compliant Standards

TWAIN, ISIS

Media Handling

Supported Document Type

Plain paper, plastic card

Document Feeder Type

Automatic

Feeder Capacity

100 sheets

Expansion / Connectivity

Interfaces Details

USB 3.0

Miscellaneous

Cables Included

1 x USB cable

Compliant Standards

RoHS

Environmental Standards

ENERGY STAR Certified

Yes

Power

Power Device

External power adapter

Voltage Required

AC 120/230 V

Power Consumption Operational (Standby)

12 Watt

Power Consumption Stand by

5.4 Watt

Power Consumption Sleep

1 Watt

Software / System Requirements

Software Included

EPSON Document Capture, EPSON Scan 2, OpenText Captiva ISIS

OS Required

Microsoft Windows 7 / 8 / 8.1 / 10, Apple MacOS X 10.10 - 10.15

Dimensions & Weight

Width

11.7 in

Depth

7.7 in

Height

12.5 in

Weight

8.16 lbs

Dimensions & Weight (Shipping)

Shipping Width

14.5 in

Shipping Depth

9.9 in

Shipping Height

11.5 in

Shipping Weight

10.58 lbs

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Environmental Parameters

Min Operating Temperature

41 °F

Max Operating Temperature

95 °F

Humidity Range Operating

10 - 80% (non-condensing)
