General

Printer Type

Workgroup printer - dot-matrix - 24 pin - monochrome

Printer

Print Speed

Up to 550 char/sec - ultra speed draft - 10 cpi ¦ Up to 584 char/sec - high speed draft - 12 cpi ¦ Up to 487 char/sec - high speed draft - 10 cpi ¦ Up to 366 char/sec - draft - 10 cpi ¦ Up to 121 char/sec - laser quality - 10 cpi

Connectivity Technology

Wired

Interface

Parallel, USB 2.0

Language Simulation

EPSON ESC/P 2, IBM PPDS

Barcodes

Matrix 2 of 5, Industrial 2 of 5, Code 39, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Codabar, Code 128, Interleaved 2 of 5, Postnet

RAM

RAM Installed (Max)

128 KB

Media Handling

Media Type

Envelopes, plain paper, continuous forms

Max Media Size

Continuous paper 4 in - 10 in (width), 10.12 in x 14.29 in

Min Media Size (Custom)

3.9 in

Max Media Size (Custom)

10.12 in

Media Sizes

Continuous paper 4 in - 10 in (width), 3.9 in x 3.9 in, 10.12 in x 14.29 in, 7.17 in x 8.27 in, 8.5 in x 14.29 in

Envelope Sizes

US No 10 (4.1 in x 9.5 in), US No 6 (3.6 in x 4.2 in)

Media Thickness Range

Up to 0.02 in

Max Sheets in Multi-Part Form

6

Expansion / Connectivity

Connections

1 x parallel ¦ 1 x USB 2.0

Miscellaneous

MTBF

25,000 hour(s)

Compliant Standards

EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class A, RoHS, FCC Part 15 B Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, CAN/CSA-C22.2 No. 60950-1, UL 62368-1

Power

Power Device

Power supply - internal

Frequency Required

50 - 60 Hz

Power Consumption Operational

57 Watt

Power Consumption Stand by

12 Watt

Power Consumption Sleep

0.4 Watt

Software / System Requirements

OS Required

Microsoft Windows XP, Microsoft Windows Server 2003, Microsoft Windows 7, Microsoft Windows Server 2008, Windows 8, Microsoft Windows Server 2012, Windows 10, Microsoft Windows Server 2016

Environmental Standards

ENERGY STAR

Yes

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Environmental Parameters

Sound Emission (Operating)

55 dBA
