General

Printer Type

Receipt printer - thermal line - monochrome

Enclosure Color

Epson black

Printer

Print Speed

Up to 300 ppm - max speed

Connectivity Technology

Wireless

Interface

USB, Gigabit LAN, USB host, USB-C

Max Resolution (B&W)

203 x 203 dpi

Max Resolution Class (B&W)

203 x 203 dpi

Fonts

Font A (12x24), Font C (9x17), Kanji Font A: 24 x 24, Kanji Font B: 20 x 24, Font B (10x24)

Character Sizes (mm)

0.0346 in x 0.0838 in, 0.049 in x 0.118 in, 0.044 in x 0.118 in, 0.098 in x 0.118 in, 2.26 x 3 mm

Columns

36, 48, 64, 24, 28, 57

Features

Open cover sensor, full / partial cutter

Auto Cutter

Yes

Barcodes

Code 93, Code 39, NW-7, GS1 DataBar, QR code, MaxiCode, Aztec code, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Codabar, Code 128, PDF417, Data Matrix, ITF, GS1-128, Composite

Printer Features

Paper end sensor, paper near end sensor

RAM

RAM Installed (Max)

4 KB

Media Handling

Media Type

Thermal paper

Max Media Size

Roll (3.13 in)

Min Media Size (Custom)

2.25 in

Max Media Size (Custom)

3.15 in

Media Sizes

Roll (3.13 in), Roll (2.3 in)

Media Thickness Range

0.0019 in - 0.003 in

Roll Maximum Outer Diameter

3.3 in

Roll Core Diameter

0.71 in

Media Feeders

1 x manual - 1 roll - Roll (3.13 in)

Networking

Networking

Print server

Expansion / Connectivity

Connections

1 x USB 2.0 - 4 pin USB Type B ¦ 1 x USB 2.0 - 24 pin USB-C/power DC jack ¦ 1 x LAN - RJ-45 ¦ 1 x USB host - 4 pin USB Type A

Miscellaneous

Media Included

1 thermal roll paper

MTBF

360,000 hours

Features

LED indicator, spill-resistant

Compliant Standards

ICES-003 Class A, RoHS, UL62368-1/CAN/CSA C22.2 No.62368-1, EMI FCC Class A

Power

Power Device

Power adapter - external

Power Consumption Operational

30.6 Watt

Power Consumption Stand by

1.4 Watt

Software / System Requirements

Software Included

EpsonNet Config, TM Utility

OS Required

Apple MacOS X, Microsoft Windows, Debian GNU/Linux, Android, Apple iOS

Environmental Standards

ENERGY STAR

Yes

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

41 °F

Max Operating Temperature

113 °F

Humidity Range Operating

10 - 90%

Sound Emission (Operating)

53 dBA

Dimensions & Weight

Width

5 in

Depth

5 in

Height

5.1 in

Weight

2.87 lbs
