Differential pressure sensor FKC - FCX-AIV V6 Series
-
NG # 2490-HW-FUJI-027
Manufactured by:
Specification
Housing L- or T-shaped housing Measuring ranges (kPa) [e.max.] 1
6
32
130
500
3000
20000Weight per kg (without indicator) 3,1 Accuracy ± 0.065% of the measurement range set as standard.
An accuracy of ±0.04% is also available as an option.Materials in contact with the process Stainless steel 316 L, Hastelloy-C, Monel, Tantalue, Stainless steel 316 L + Gilding, Monel coating, Tantalue coating Case materials Low-copper aluminum alloy with polyester coating, or 316 L stainless steel Membrane materials Stainless steel 316 L
Hastelloy-C
Monel
Tantalum
Stainless steel 316 L and Gilding
Gilding and CeramicsStability ±0.1% of maximum scale for 10 years for digit
6 = 3, 5, 6, 8 and 9.Elevation / Deletion From -100 to +100% of maximum scale Scale setting range 1 to 1/100 of maximum scale Measurement cycle 40 ms Communication protocol HARTTM 7 communication protocol Process temperature From +40° to +120°C (versions for higher temperatures are available) Ambient temperature From -40° to +85 °C Power supply 10.5 to 45 V DC Output signal / Load resistance 4-20 mA / 250 Ω typical Damping Configurable between 0.04 and 32 secs Zero and span adjustment Via external sensor screw, local three-button display or HARTTM protocol Electrical connections M20x1.5" / 1/2 - 14 NPT / Pg13.5 Options Digital indicator, degreasing treatment, oxygen service, chlorine service, additional stainless steel identification plate
Description
DIFFERENTIAL PRESSURE TRANSMITTER – FKC : ACCURACY AND RELIABILITY FOR YOUR INDUSTRIAL PRESSURE MEASUREMENTS The differential pressure transmitter FKC from Fuji Electric is designed to provide optimal accuracy in pressure measurement across various industrial environments. Robust and reliable, it is suitable for applications requiring precise differential pressure control, ensuring efficient process management. FEATURES OF THE DIFFERENTIAL PRESSURE TRANSMITTER – FKC - High measurement accuracy thanks to silicon micro-machined sensor technology - Wide pressure range available to meet different industrial needs - Excellent long-term stability, reducing calibration requirements - Robust design with resistance to harsh environments - Integrated HART digital communication for easy system integration - ATEX-certified for hazardous areas - Compliance with SIL2 / SIL3 safety integrity levels APPLICATIONS The FKC differential pressure transmitter is used in industries such as petrochemicals, energy, water treatment, and food processing to monitor and regulate processes with high precision. ADVANTAGES Increased reliability thanks to robust design and excellent long-term stability Versatility with a wide range of pressure levels and configurations Guaranteed safety with certifications for demanding environments Reduced maintenance costs due to low drift and minimal calibration needs
