Krohne OPTIFLUX 1300
-
NG # 006604-HW-KROHNE-004
Manufactured by:
The OPTIFLUX 1300 is an electromagnetic flowmeter (EMF) with lightweight wafer-style design. The meter is an economical solution for applications with conductive liquids (≥ 5 μS/cm) and higher solid content (up to 70%). Unlike the OPTIFLUX 1100, the OPTIFLUX 1300 offers a better accuracy. The flowmeter already meets the demands of many applications in various industries. It has established itself as the preferred solution for OEM machinery applications, dosing systems, compact skids, chemical handling systems or pump and firefighting systems
Specification
General information
| Product type | Flowmeter |
| Product family name | OPTIFLUX |
| Product positioning | For OEM applications, dosing systems and compact skids |
| Measurement principle | Electromagnetic |
| Measured media | Liquids |
Operating conditions
| Process pressure | max. 16 barg/ 230 psig |
| Process temperature | -25…+120°C/ -13…+248°F |
Materials
| Liner | Perfluoroalkoxy alkane (PFA) |
Process connections
| Flange connections | Counter flanges: EN (1092-1): DN10…150 ASME (B 16.5): ⅜…6" JIS (B 2220): 10…150A |
| Other connections | Sandwich (wafer) connection: DN10...150 ⅜…6" 10…150A |
Approvals/Standards
| Certificates/Approvals Ex | ATEX, FM, CSA |
| Certificates/Approvals Marine | ABS, BV, CCS, DNV, KR, LR, NK, RINA, CRS, IRS, PRS, RS |
Communication
| Analogue outputs | 4…20 mA |
| Discrete outputs | Limit switches, Pulse, Frequency, Status |
| Digital outputs | FOUNDATION™ Fieldbus, HART®, Profibus-PA, Profibus-DP, Modbus RTU, PROFINET |
Description
Electromagnetic flowmeter for OEM applications, dosing systems and compact skids
Economical flow measurement of liquids (≥5 μS/cm) with solid content (≤70%)
-25…+120°C / -13…+248°F
Wafer-style design: DN10…150 / ⅜…6", max. PN40 / ASME Cl 300
3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET
