Krohne OPTIFLUX 2050
-
NG # 006605-HW-KROHNE-005
Manufactured by:
The OPTIFLUX 2050 is an electromagnetic flowmeter (EMF) for basic water and wastewater applications. It is suitable for all cost-effective measurements where extremely high accuracy, extensive diagnostics or a wide range of communication options are not a priority. The EMF has a wide diameter range (DN25…1200 / 1…48") and all drinking water approvals. The extra isolation of the electronic device and housing makes this EMF particularly suitable for use in areas with extreme humidity.
Specification
General information
| Product type | Flowmeter |
| Product family name | OPTIFLUX |
| Product positioning | For basic water and wastewater applications |
| Measurement principle | Electromagnetic |
| Measured media | Liquids |
Operating conditions
| Process pressure | max. 40 barg/ 580 psig |
| Process temperature | -5…+90°C/ +23…+194°F |
Materials
| Liner | Polypropylene (PP), Hard rubber |
Process connections
| Flange connections | EN (1092-1): DN25…1200 ASME (B 16.5): 1…48" JIS (B 2220): 25…1000A |
Approvals/Standards
| Certificates/Approvals Marine | ABS, BV, CCS, DNV, KR, LR, NK, RINA, CRS, IRS, PRS, RS |
| Certificates/Approvals Potable Water | DVGW, NSF, TZW, KTW, WRAS, KIWA, ACS |
Communication
| Analogue outputs | 4…20 mA |
| Discrete outputs | Pulse, Frequency, Status |
| Digital outputs | HART®, Modbus RTU |
Description
The OPTIFLUX 2050 features a full bore design with wear resistant liner materials. Installation in measurement chambers subject to (constant) flooding is possible with the IP68 / NEMA 6P rated version. The EMF comes with current output (incl. HART®) or active pulse/frequency output and Modbus. A full on-site verification of the OPTIFLUX 2050 without process interruption can be carried out using the OPTICHECK service tool.
