Krohne OPTIMASS 7010
-
NG # 006617-HW-KROHNE-017
Manufactured by:
The OPTIMASS 7010 is a high-end single straight tube Coriolis mass flowmeter. It is particularly suitable for demanding process and dosing applications involving gases and shear-sensitive or viscous liquids, slurries, very aggressive media or media with a low flow velocity.
Specification
General information
| Product type | Flowmeter |
| Product family name | OPTIMASS |
| Product positioning | For advanced applications and process control |
| Measurement principle | Coriolis |
| Measured media | Liquids, Gases |
Operating conditions
| Process pressure | max. 100 barg/ 1450 psig |
| Process temperature | -40…+150°C/ -40…+302°F |
Materials
| Measuring tube | Austenitic alloy (2.4602/Alloy 22), Duplex stainless steel (1.4462/318), Titanium alloy (3.7195/Ti-Grade 9), Tantalum (UNS RO5255 / RO5200) |
Process connections
| Flange connections | EN (1092-1): DN10…100 ASME (B 16.5): ½…4" JIS (B 2220): 10…100A |
| Hygienic connections | Clamp (DIN 32676): DN10, DN15, DN25, DN40, DN50, DN80 Clamp (ISO 2852): 25, 40, 51, 76.1 Tri-Clamp: ½", ¾", 1", 1½", 2", 3" Threaded ferrule (DIN 11851): DN10, DN15, DN25, DN40, DN50, DN80 Flange with groove (DIN 11864-2): DN10, DN15, DN25, DN40, DN50, DN80 Threaded ferrule (SMS 1146): 25 mm, 38 mm, 51 mm, 76 mm IDF/ISS: 10A, 15A, 1", 1½", 2", 3 |
Approvals/Standards
| Certificates/Approvals Ex | ATEX, IECEx, EAC Ex, INMETRO, FM |
| Certificates/Approvals Hygienic | FDA, 3A, EHEDG, EC 1935/2004 |
| Certificates/Approvals Marine | ABS, BV, CCS, DNV, KR, LR, NK, RINA, CRS, IRS, PRS, RS |
Communication
| Digital outputs | Modbus RTU, EtherNet/IP™ |
Description
The Coriolis meter features an integrated Modbus converter. This makes it the ideal solution for applications where a DCS or a PLC is already in use and extensive communication options and control functions are not necessary. By way of its Modbus interface the flowmeter integrates easily into existing controller systems. There is no need for a conventional signal converter. Purchase costs can be saved.
