Krohne WATERFLUX 3050
-
NG # 006610-HW-KROHNE-010
Manufactured by:
The WATERFLUX 3050 is an electromagnetic flowmeter (EMF) for basic water applications. It offers cost-effective flow measurement in applications where extremely high accuracy, extensive diagnostics or a wide range of digital communication options are not a priority.
Specification
General information
| Product type | Flowmeter |
| Product family name | WATERFLUX |
| Product positioning | For basic water applications |
| Measurement principle | Electromagnetic |
| Measured media | Liquids |
Operating conditions
| Process pressure | max. 16 barg/ 230 psig |
| Process temperature | -5…+70°C/ +23…+158°F |
Materials
| Liner | Polyamide polymer 11 (Rilsan®) |
Process connections
| Flange connections | EN (1092-1): DN25…600 ASME (B 16.5): 1…24" JIS (B 2220): 25…600A |
| Thread connections | Male: G1, G1½, G2 |
Approvals/Standards
| Certificates/Approvals Marine | ABS, BV, CCS, DNV, KR, LR, NK, RINA, CRS, IRS, PRS, RS |
| Certificates/Approvals Potable Water | DVGW, NSF, TZW, KTW, WRAS, KIWA, ACS |
Communication
| Analogue outputs | 4…20 mA |
| Discrete outputs | Pulse, Frequency, Status |
| Digital outputs | HART®, Modbus RTU |
Description
Its measuring tube with a rectangular and reduced cross-section enables a stable measurement even at low flow rates. Due to the optimized flow profile, the meter is practically independent of interferences from the installation environment. It can be installed virtually anywhere without straight inlet or outlet runs – behind pipe bends, slide valves or a reduction in the pipe.
