UltiMaker S3 3D Printer
TF:
006476-HW-TEK-076
Overview
The UltiMaker S3 features next-generation reliability. Its advanced active leveling, stiffer build platform, heated build plate, and more accurate stepper drivers result in high print quality for a machine in this form factor. And dual filament flow sensors notify you if you run out of material.
| Dimensions | |
| Build volume | 230 x 190 x 200 mm (9 x 7.4 x 7.9 inches) |
| Assembled dimensions | W 394 x D 489 x H 637 mm (W 15.5 x D 19.3 x H 25.1 inches) |
| Print technology | Fused Deposition Modeling (FDM) |
| Compatible filament diameter | 2.85 mm |
| Weight | 14.4 kg (31.7 lbs) |
| Maximum power output | 350 W |
| Operation parameters | |
| Build speed | < 24 mm³/s |
| Nozzle temperature | 180 - 280 °C |
| Nozzle heat-up time | < 2 minutes |
| Operating sound | < 50 dBA |
| Build plate leveling | Advanced active leveling |
| Build plate | 20 - 140 °C heated glass build plate |
| Build plate heat-up time | < 4 minutes (from 20 to 60 °C) |
| Operating ambient temperature | 15 - 32 °C (59 - 90 °F) |
| Printer properties | |
| Layer resolution | 0.25 mm nozzle: 150 - 60 micron 0.4 mm nozzle: 200 - 20 micron 0.6 mm nozzle: 300 - 20 micron 0.8 mm nozzle: 600 - 20 micron |
| XYZ resolution | 6.9, 6.9, 2.5 micron |
| Feeder type | Dual-geared feeder, reinforced for composite materials |
| Display | 4.7-inch (11.9 cm) color touchscreen |
| Print core replacement | Swappable print cores |
| Print head | Dual extrusion print head with an auto-nozzle lifting system, swappable print cores. |
| Nozzle diameters | 0.25 mm, 0.4 mm, 0.6 mm, 0.8 mm |
| Supplied free software | UltiMaker Cura – print preparation software UltiMaker Digital Factory – printer management software UltiMaker Essentials – enterprise-grade online software tools |
| Supported OS | MacOS, Windows, and Linux |
| Plugin integration | SolidWorks, Siemens NX, Autodesk Inventor |
| Supported file types | UltiMaker Cura: STL, OBJ, X3D, 3MF, BMP, GIF, JPG, PNG Printable formats: G, GCODE, GCODE.gz, UFP |
| File transfter | Wi-Fi (2.4 GHz), Ethernet, USB |
| Certification | CE, FCC, VPAT, RoHS, REACH, CB, BIS, KC, PSE, RCM, SRRC, MIC, NCC, Safe unattended professional use |
The UltiMaker S3 was designed so that anyone can achieve high-quality results after a 30-minute introduction. Its award-winning touch interface, advanced active leveling, predefined print settings, and UltiMaker Platform access, facilitate 3D printing as part of any workflow.
