Pepperl+Fuchs 3-D Time-of-Flight sensor VTE7500-F400-B12-A1500
-
NG # 003404-HW-Pepperl-OO4
Manufactured by:
The 3-D time-of-flight sensor is based on the principle of measuring time-of-flight of infrared light. This allows raw 3-D data from objects at a range of 400 to 7500 mm to be acquired with an image resolution of 0.3 MP and a frame rate of 30 fps
Specification
Detection range max. 7500 mm, min. 400 mm Light source Vertical-cavity surface-emitting laser Light type Infrared Laser nominal ratings Laser class 1 Wave length 940 nm Target velocity max. 1 m/s Object reflectivity > 18 % Picture detail dependant of operating distance Opening angle 47 ° x 35 ° Camera Number of pixels 640 x 480 pixels Shutter 4 - Phases Global shutter Frame rate 30 fps Image resolution 0.3 MP MTTFd 20 a Mission Time (TM) 10 a Diagnostic Coverage (DC) 0 % Operating voltage 24 V ± 20 % , PELV No-load supply current max. 450 mA Power consumption max. 13 W , Outputs without load Interface type Ethernet TCP/IP Transfer rate 1 GBit/s Degree of protection IP65/IP67 Connection M12 connector, 8-pin , A-coded 8-pin M12 socket , X-coded Installation M5 screws Mass approx. 800 g
Description
The 3-D time-of-flight sensor is based on the principle of measuring time-of-flight of infrared light. This allows raw 3-D data from objects at a range of 400 to 7500 mm to be acquired with an image resolution of 0.3 MP and a frame rate of 30 fps.
The sensor features a Gigabit Ethernet interface, intuitive operating software, rugged metal housing, and an API interface. The sensor is especially suitable for dynamic applications with a larger measuring range.
