Winmate L140AD-4L 14-inch Rugged notebook
-
NG # 003802-HW-WIN-O02
Manufactured by:
L140AD-4L 14-inch Rugged notebook with Intel® Core™ i5-1235U
Specification
Display Size 14.0 inches Resolution 1920x1080 Panel Brightness 300.0 nits Contrast Ratio 800:1 View Angles 85,85,85,85 System Specification Processor Intel Core i5-1235U (up to 4.4GHz) Memory 8GB DDR5 SDRAM
16GB DDR5 SDRAM (Optional)
32GB DDR5 SDRAM (Optional)Storage 256GB M.2 NVMe SSD
512GB M.2 NVMe SSD (Optional)
1TB M.2 NVMe SSD (Optional)
2TB M.2 NVMe SSD (Optional)
2nd storage available with up to 2TB M.2 NVMe SSD (Optional)Smart Card Reader Smart Card Reader (Mutually exlcusive with 2nd LAN)(Optional) Security Trusted Platform Module (TPM) 2.0
Kensington LockOperating System Windows 11 IoT Enterprise LTSC (64 bit)
Windows 10 IoT Enterprise LTSC (64 bit) (Optional)WLAN Support BT Support WWAN 4G LTE (Optional)
5G (Optional)Camera Front Camera 2MP front camera Mechanical Dimension 340 x 230 x 38 mm Weight 2.35 kg Cooling System Fan Design IO Ports USB Port 1 x USB 3.0 (Type C)
3 x USB 3.0 (Type A) (One USB-A is mutually exclusive with 2nd LAN)LAN 1 x RJ45-10/100/1000 GigaLAN port
Optional 2nd LAN (Mutually exlcusive with one USB-A & Smart Card Reader)Video 1 x HDMI 4K Output (Optional) Audio 1 x Audio combo 3.5mm audio combo jack
Dual Digital Mic With Noise Cancellation
Dual SpeakerSD Card Slot 1 x Micro SDXC Slot SIM Card Slot 1 x Nano SIM card slot Indicator 2x LED Indicator for Power, Battery Environment Operating Humidity 10% to 90% RH, non-condensing Operating Temperature -10°C to 50°C Storage Temperature -30°C to 70°C Shock MIL-STD-810H Method 516.8 Procedure I Vibration MIL-STD-810H Method 514.8 Procedure I Drop MIL-STD-810H Method 516.8, 4 ft IP rating IP65 Certification Certification CE, FCC Security Function SOTI MobiControl SOTI MobiControl Compliance Kensington Lock Kensington Lock Support Control Button QWERTY keyboard with backlight Power Battery Hot-swappable 2 x 11.55V, typ. 3220 mAh Li-Ion Battery (3S1P) Battery Operating Time Standard Battery: 11 hours Power Rating 19V DC Adapter 100-240V, 50-60Hz / 19V DC Accessory Accessory Adapter and Power Cord
Standard BatteryOptional Accessory Spare Battery (Optional)
Battery Charger (Optional)
Vehicle Charger (Optional)
Carry Bag (Optional)
Description
Durability for Harsh Environment Durable Build: Winmate Rugged Laptop is designed with a robust and durable exterior, compliant with US Defence Standard (MIL-STD-810H) for guaranteed performance. Winmate Rugged Laptop also certified with an IP65 rating, ensuring water and dust resistant.
