Zebra EM45 Enterprise Mobile
-
NG # 005102-HW-ZABRA-002
Manufactured by:
Zebra EM45 Enterprise Mobile combines the power of Zebra with the sleek, ergonomic feel of a consumer device, delivering unmatched productivity and flexibility to your frontline. With its lightweight and slim design, EM45 is perfect for field sales, drivers, store managers, and others — providing instant communication over 5G and Wi-Fi 6E, along with the flexibility to seamlessly integrate with enterprise solutions powered by Zebra.
Specification
Dimensions 6.72 in L x 3.17 in W x .42 in D
(170.65mm L x 80.54mm W x 10.7mm D)Weight 8.57 oz (243g) (with battery) Display 6.7 in color Full High Definition+ (2400 x 1080); LED backlight; dynamic 120Hz refresh rate Touch Panel Multi mode capacitive touch with bare or light gloved fingertip input; water droplet rejection, Oleophobic coating Power Service replaceable; rechargeable Li-Ion, PowerPrecision for real-time battery metrics; Standard Capacity: 4,750mAh/18.43Wh Expansion Slot User-accessible MicroSD card; supports up to 2 TB SIM Dual SIM (single Nano SIM and eSIM) Network Connections WWAN; Wi-Fi, Bluetooth and NFC Notifications Audible tone; vibration Keypad On-screen keypad Voice and Audio Two microphones with noise cancellation; HAC compliant (North America); Dual Stereo speakers for loudness; High Quality stereophonic speaker phone; Bluetooth wireless headset support; PTT headset (Zebra USB-C) support; HD VoIP, Voice and Multimedia, supporting Super-wideband
(SWB), Wideband (WB) and Full band (FB)Buttons Volume up/down; Power (fingerprint biometrics). Programmable action buttons: Left - default to scan; Right - default to PTT; Top - default to camera Interface Ports USB 3.1 (Bottom Type C) — SuperSpeed (host and client); OTG/host charging mode
Performance Characteristics
| CPU | Qualcomm® 5430 Octa-core, 2.2 GHz |
| Operating System | Android; for supported Android versions |
| Memory | 8 GB DDR5 RAM/128 GB UFS3.1 Flash |
User Environment
| Operating Temperature | +32F to +122F (0C to +50C) |
| Storage Temperature | -40F to +158F (-40C to +70C) |
| Humidity | 5% — 95% non-condensing |
| Drop Specification | 5 ft (1.5m) to tile over concrete across temperature (0C to +50C/+32F to +122F) with protective boot exceeding MIL-STD-810H; Multiple 4 ft (1.2m) to tile over concrete across temperature (0C to +50C/+32F to 122F) exceeding MIL-STD 810H |
| Tumble Specification | 600 1.6 ft (0.5m) tumbles for device with protective case; 300 1.6 ft (0.5m) tumbles for device (1.6 ft/0.5m) |
| Sealing | IP68 and IP65, with battery per applicable IEC sealing specifications |
| Vibration | Sine: 4 g’s peak, 5hz to 2khz; Random:0.04 g²/hz, 20hz to 2khz |
| Thermal Shock | -40F to +158F (-40C to +70C) |
| Electrostatic Discharge (ESD) | +/-15 kV air discharge, +/-8 kV direct discharge; +/-8 kV indirect discharge |
General Certifications
| Google ARCore certified; Android Enterprise Recommended (AER) certified, AT&T/Verizon certified |
Interactive Sensor Technology (IST)
| Motion Sensor | 3-axis accelerometer with MEMS Gyro |
| Light Sensor | Automatically adjusts display backlight brightness |
| Proximity Sensor | Automatically detects when the user places the device against head during a phone call to disable display output and touch input |
| Magnetometer | eCompass to detect direction |
| Pressure Sensor | Altitude detection for locating |
Data Capture
| Scanning | Camera-based scanning, leveraging Zebra’s advanced decoder library for accurate and efficient data capture — complimentary with the device |
| Camera | Rear: 50 MP, Auto focus, OIS; ƒ/1.9, Video Recording Resolution: UHD 4K (3840x2160) @30fps, Front: 8 MP, ƒ/2.0, Video recording 1080P@30fps |
| NFC | ISO 14443 Type A and B; Sony FeliCa5 and ISO 15693 cards; Card Emulation via Host; Contactless payment support; ECP1.0 and ECP2.0 polling support; Apple VAS certified |
Wireless LAN
| WLAN Radio | IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc; 2x2 MU-MIMO; Tri-band (2.4 GHz, 5 GHz, 6 GHz); Wi-Fi CERTIFIED 6™ (Wi-Fi 6E); Dual Band Simultaneous; IPv4, IPv6 |
| Data Rates | 2.4 GHz: 802.11b/g/n/ax — 20 MHz - up to 286.8 Mbps; 5 GHz: 802.11a/n/ac/ax — 20 MHz, 40 MHz, 80 MHz, 160 MHz - up to 2402 Mbps; 6 GHz: 802.11ax — 20 MHz, 40 MHz, 80 MHz, 160 MHz — up to 2402 Mbps |
| Operating Channels | Channel 1-13 (2401-2483 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13; Channel 36-165 (5150-5850 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165; Channel 1-233 (5925-7125 MHz); Channel Bandwidth: 20, 40, 80, 160 MHz; Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency |
| Security and Encryption | WPA3 Enterprise 192-bit mode (GCMP256) — EAP-TLS; WPA3 Enterprise, AES-CCMP-128 — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Personal (SAE), AES-CCMP-128; WPA/WPA2 Enterprise, TKIP and AES-CCMP-128; WPA/WPA2 Personal (PSK), TKIP and AES-CCMP-128; Enhanced Open (OWE), AES-CCMP-128; WEP 40 bit and 104 bit; WAN device only: EAP-SIM, EAP-AKA, EAP-AKA Prime |
| Certifications | Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6 (Wi-Fi 6E); WPA2-Personal; WPA2-Enterprise; WPA3-Personal; WPA3-Enterprise (includes 192-bit mode); Protected Management Frames; Wi-Fi Enhanced Open; WMM (Wi-Fi Multimedia); WMM-Power Save; WMM-Admission Control; Voice-Enterprise; Wi-Fi Direct; Wi-Fi Agile Multiband; Wi-Fi QoS Management; Wi-Fi Optimized Connectivity; Passpoint |
| Fast Roam | 802.11r Fast BSS Transition; PMK Caching; Cisco CCKM; OKC |
Wireless WAN
| Radio Frequency Band6 | North America: 5G FR1: n2/5/7/8/12/13/14/25/26/29/30/38/41/48/66/71/77/78; 4G: B2/4/5/7/8/12/13/14/17/25/26/29/30/38/41/48/66/71; 3G: B2/4/5 Rest of World: 5G FR1: n1/2/3/5/7/8/20/26/28/38/40/41/66/71/77/78; 4G: B1/2/3/4/5/7/8/13/17/18/20/26/28/38/39/40/41/42/43/66/71; 3G: B1/2/4/5/6/8/19; 2G: 850/900/1800/1900 Dual SIM/Dual Standby, VoLTE, Gigabit LTE-A, 5G NR Sub-6 (NSA, SA), LTE/NR Carrier Aggregation, Supports private 5G/LTE; CBRS (available only in the US) |
| GPS | GPS, GLONASS, Galileo, Beidou, QZSS; Dual-Band GNSS — concurrent L1/G1/E1/B1; (GPS/QZSS, GLO, GAL, BeiDou) + L5/E5a/BDSB2a (GPS/QZSS, GAL, BeiDou); a-GPS; supports XTRA |
| Multimedia | Wi-Fi Multimedia™ (WMM) and WMM-PS; Including TSPEC |
Wireless PAN
| Bluetooth | Class 1, Bluetooth v5.3; Classic Bluetooth(BR/EDR) & Bluetooth LE |
Description
With the power to unlock AI capabilities, a cutting-edge processor, fast memory, and a high-performance camera, EM45 delivers a fast, reliable experience. A battery with up to 25 hours of life supports your workforce all day long, while enterprise-level security and authentication protect your operations. Plus, Zebra DNA software suite simplifies setup, deployment and device management, reducing IT complexity because all your devices can now run on a Zebra common enterprise platform. From retail to field services and healthcare to transportation and logistics, companies already trust Zebra — now they can unlock even greater potential to empower their enterprise workforce. Zebra EM45 — built for work. Designed for you.
